Tuam Tshoj Industrial Caster Chaw tsim tshuaj paus
Peb yog ib lub Hoobkas Peb yog cov chaw tsim khoom thiab cov chaw tsim khoom ntawm Industrial Caster, muab cov khoom thauj -cov kabmob txav mus los siv hauv cov tshuab thauj khoom, cov cuab yeej tuav lub platform, thiab cov khoom siv txav mus los. Cov Casters yog cov cuab yeej siv lub log uas muaj peb qhov tseem ceeb: lub cev lub cev (polyurethane, nylon, roj hmab, cam khwb cia hlau, phenolic resin), bracket qauv (carbon steel stamping, welded steel, stainless hlau), thiab bearing system (ib pob bearing, ob lub npas kabmob, tapered menyuam bearing).
Muaj Casters yog siv nyob rau hauv ib puag ncig uas cov khoom yuav tsum tau tsiv mus nyob rau hauv static los yog dynamic load tej yam kev mob. Lawv tau siv rau hauv pem teb -raws li kev thauj mus los, kev tsim khoom siv mobile, thiab cov cuab yeej siv hnyav. Lub hom phiaj ntawm engineering yog kom txo tau cov dov tsis kam, tswj kev txav mus los, faib cov khoom thauj mus rau hauv pem teb, thiab tswj kev ruaj ntseg hauv kev ua haujlwm tas mus li.
thiab tus neeg muag khoom ntawm Industrial Caster, muab cov khoom thauj-cov kabmob txav mus los siv hauv cov tshuab thauj khoom, cov cuab yeej tuav lub platform, thiab cov khoom siv txav mus los. Cov Casters yog cov cuab yeej siv lub log uas muaj peb qhov tseem ceeb: lub cev lub cev (polyurethane, nylon, roj hmab, cam khwb cia hlau, phenolic resin), bracket qauv (carbon steel stamping, welded steel, stainless hlau), thiab bearing system (ib pob bearing, ob lub npas kabmob, tapered menyuam bearing).
Muaj Casters yog siv nyob rau hauv ib puag ncig uas cov khoom yuav tsum tau tsiv mus nyob rau hauv static los yog dynamic load tej yam kev mob. Lawv tau siv rau hauv pem teb -raws li kev thauj mus los, kev tsim khoom siv mobile, thiab cov cuab yeej siv hnyav. Lub hom phiaj ntawm engineering yog kom txo tau cov dov tsis kam, tswj kev txav mus los, faib cov khoom thauj mus rau hauv pem teb, thiab tswj kev ruaj ntseg hauv kev ua haujlwm tas mus li.
Hom ntawm Peb Muaj Caster
Muaj Caster Technical Specification & Customization Guide
Cov kev xaiv dav dav, cov khoom lag luam, kev txheeb xyuas daim ntawv thov, thiab cov txheej txheem kev koom ua ke engineering rau siab -kev ua tau zoo hauv kev lag luam.
Hais txog pebCustomization txheej txheem
Muaj Caster xaiv thiab customization yog raws li cov neeg kho tshuab thiab ib puag ncig tsis:
- Load tsom xam (zoo li qub load, dynamic load, cuam tshuam load ib lub log)
- Cov khoom siv log xaiv raws li hauv pem teb (PU / nylon / roj hmab / steel)
- Kev xaiv cov kabmob (tsis tshua muaj kev sib txhuam vs siab load vs siab kub)
- Mounting interface txhais (sab saum toj phaj / threaded qia / ntsia liaj qhov rooj qhov / expansion qia)
- Swivel mechanism tsim (nrog lossis tsis muaj nres)
- Environmental condition check (humidity, corrosion, tshuaj raug, kub)
- Structural reinforcement rau ncej compatibility
Yam khoom
1. Warehouse & Logistics Caster
- Load ntau:100-600 kg ib lub log
- Cov khoom siv log:polyurethane / nylon
- pallet tsheb, mobile racks, sorting carts
- Feature tsom:dov efficiency ntawm epoxy lossis pob zeb hauv pem teb
2. Kev Lag Luam Kev Lag Luam Caster
- Load ntau:200-1500 kg ib lub log
- Cov khoom siv log:PU nrog steel tub ntxhais / cam khwb cia hlau
- Daim ntawv thov:sib dhos kab fixtures, tooling carts, ntau lawm hloov tshuab
- Feature tsom:kev co tswj thiab kev taw qhia stability
3. Heavy Engineering & Siv Caster
- Load ntau:800-3000 kg ib lub log
- Cov khoom siv log:forged steel / reinforced polyurethane
- Daim ntawv thov:pwm thauj tshuab, steel qauv txav, hnyav machinery puag
- Feature tsom:siab load faib thiab poob siab kuj
4. Kub kub Caster
- Qhov kub thiab txias:mus txog 280-300 degree
- Cov khoom siv log:phenolic resin / tshav kub- kho steel
- Daim ntawv thov:qhov cub lub laub, kho cua sov racks
- Feature tsom:thermal stability thiab deformation kuj
5. Corrosion-Resistant Caster
- Khoom siv:Stainless hlau 304 / 316 ncej
- Log:nylon / stainless hlau / anti-corrosion PU
- Daim ntawv thov:marine engineering, tshuaj nroj tsuag, offshore platforms
- Feature tsom:tsis kam mus rau ntsev tsuag thiab tshuaj lom neeg raug
Technical Parameters
- Load peev ib lub log:100-3000 kg
- Log diameter:75mm-400 hli
- Lub log dav:30mm-100 hli
- Hom kabmob:
- Sib sib zog nqus groove pob bearing (tsis tshua muaj kev sib txhuam, nruab nrab load)
- Precision roller bearing (siab load, muaj khoom siv)
- Plain bearing (tus nqi qis, kev siv ceev ceev)
- Qhov kub thiab txias:-30℃rau +300℃(khoom siv)
- Swivel Structure:ib pob sib tw / ob lub pob sib tw
- Nres system:sab xauv / tag nrho cov xauv (lub log + tig)
- Mounting hom:
- Sab saum toj phaj mounting (tus qauv muaj ncej)
- Threaded qia mounting (adjustable khoom puag)
- Bolt qhov mounting (hnyav- lub luag haujlwm thav duab)
Daim ntawv thov
Muaj Casters yog siv rau hauv cov tshuab tshuab uas xav tau kev tswj kev txav hauv qab:
Warehouse & Logistics
Mobile shelving systems, conveyor hloov lub laub, xaj xaiv trolleys, faib tuav platforms
Kev Lag Luam Kev Lag Luam
Automotive sib dhos fixtures, cav thauj jigs, PCB ntau lawm laub, tooling changeover systems
Heavy Engineering & Kev Tsim Kho
Steel qauv positioning systems, turbine tu platforms, pwm thauj mus los hauv paus, hnyav skid systems
Zog & Txheej Txheem Kev Lag Luam
LNG cog tu lub laub, pipeline valve tuav trolleys, roj teeb module thauj tshuab
Marine & Offshore Engineering
Lub laub khoom siv lawj, corrosion-tsheb thauj mus los, cov kev pabcuam sab nraud
Kev sib piv
Muaj Caster vs Fiberglass Sliding Skids
| Yam khoom | Muaj Caster | Fiberglass Skid |
|---|---|---|
| Motion hom | Rolling zog | zawv zawg kev sib txhuam |
| Kev sib txhuam coefficient | Tsawg (0.02-0.05 PU log) | Siab (0.2-0.4) |
| Load mobility | Kev txav mus tas li | Intermittent repositioning |
| Kev tu | Cov kabmob yuav tsum tau kho | Kev saib xyuas yam tsawg kawg nkaus |
Muaj Caster vs Pob Zeb Wool Base Txhawb
| Yam khoom | Muaj Caster | Pob zeb Wool Support |
|---|---|---|
| Muaj nuj nqi | Mobile load hloov | Static rwb thaiv tsev txhawb nqa |
| Lub luag haujlwm ntawm tus qauv | Movement + load bearing | Thermal rwb thaiv tsev nkaus xwb |
| Reusability | Siab | Txwv cov qauv rov siv dua |
| Mechanical kev ua tau zoo | Tsim los rau dynamic load | Tsis yog tsim los rau cov tshuab ua haujlwm |
Kev teeb tsa
Muaj Caster installation nyob ntawm txoj kev mounting thiab load class:
1. Sab saum toj phaj Installation
- Teem lub bolt qauv nrog cov khoom siv puag ncej
- Siv siab - lub zog bolts (feem ntau qib 8.8 lossis siab dua)
- Tighten nyob rau hauv tus ntoo khaub lig- qauv sib lawv liag kom tsis txhob deformation
- Xyuas kom mounting nto flatness nyob rau hauv tsawg tshaj li los yog sib npaug rau 0.5 mm kam rau ua
2. Threaded qia Installation
- Ntxig qia rau hauv lub qhov (socket) threaded los yog ntxig lub raj
- Siv cov txiv ntoo xauv kom tsis txhob xoob hauv qab vibration
- Siv lub tshuab ntxhua khaub ncaws rau kev faib khoom
3. Bolt Qhov Installation
- Los ntawm -bolt kev twb kev txuas siv hauv hnyav- lub luag haujlwm thav duab
- Pom zoo rau kev thauj khoom siab dua 1000 kg ib lub log
Installation checks:
- Log rotation clearance tsis muaj kev cuam tshuam
- Swivel rotation angle verification (360℃dawb txav)
- Load faib uniformity ntawm txhua lub log
- Kev sib cuag hauv pem teb nyob rau hauv kev ntsuas load
FAQ
1. Kuv yuav txiav txim siab load npaum li cas rau cov Casters muaj nyob rau hauv ntau- lub log tsheb?
Tag nrho cov load ÷ tus naj npawb ntawm lub log × qhov kev nyab xeeb (feem ntau yog 1.3-1.5), xav txog qhov tsis sib xws ntawm kev thauj khoom.
2. Dab tsi ua rau qhov chaw tiaj tus ntawm Caster log?
Ntev - lub sij hawm zoo li qub loading tshaj li cov ntaub ntawv compression txwv, tshwj xeeb tshaj yog nyob rau hauv PU los yog roj hmab log.
3. Caster hom twg haum rau epoxy flooring?
Polyurethane log nrog nruab nrab hardness (Shore A 85-95) feem ntau yog siv.
4. Cov Casters puas tuaj yeem siv rau hauv qhov chaw sab nraum zoov?
Yog lawm, tab sis stainless hlau thav duab thiab corrosion - cov ntaub ntawv log resistant yuav tsum tau.
5. Dab tsi yog qhov txawv ntawm pob bearing thiab cov menyuam bearing hauv Casters?
Pob bearings txo dov tsis kam; cov menyuam bearings tuav ntau dua radial loads.
6. Qhov kub thiab txias cuam tshuam li cas Caster kev ua tau zoo?
Cov kub kub tuaj yeem deform lub log polymer; Qhov kub tsis tshua muaj peev xwm nce brittleness nyob ntawm cov khoom siv.
7. Dab tsi yog qhov ua tsis tau zoo hauv cov Casters?
Cov kabmob hnav, qag deformation, lossis log tread degradation nyob rau hauv cov xwm txheej dhau.
Rau kev xaiv engineering thiab daim ntawv thov sib piv:
- ✓ Thov cov ntaub ntawv technical (load curve, material specification, dimensional drawing)
- ✓ Tau txais CAD cov ntaub ntawv (STEP / DWG hom)
- ✓ Nug cov qauv coj mus kuaj hauv pem teb thiab thauj khoom
- ✓ Thov kev them nyiaj yug load rau ntau-Caster systems
- ✓ Kev txhawb nqa rau mounting qauv tsim thiab kev koom ua ke
Xa koj daim ntawv thov kev lag luam Caster rau engineering configuration thiab specification matching.
Xav tau Engineering Assistance?
Txuas ncaj qha nrog peb pab neeg ua haujlwm kom tau txais CAD specs, datasheets, thiab load xam raws li koj xav tau.
Xa Kev Tshawb Fawb Txog Kev Tshawb Fawb →Raws li ib qho ntawm cov kws tshaj lij kev lag luam caster tuam ntxhab thiab cov muag khoom hauv Suav teb txij li xyoo 1997, peb tau tshwj xeeb los ntawm cov khoom pheej yig thiab cov kev pabcuam zoo. Thov so assured mus ua lag luam wholesale zoo casters ntawm tus nqi sib tw los ntawm peb lub hoobkas.
